Single-Phase ATS/Switched PDU with LX Platform Interface, 8 Outlets, 12 ft Cord
New
New
New
Provides a redundant power option for single-corded network devices. Dual input cords support separate connection to primary and secondary power sources. The ATS will normally maintain continuous output to all outlets as derived from the primary input cable. If the primary power source becomes unstable or fails altogether, the ATS will switch over to the secondary power source until the primary input is restored and stable. Features include individually controllable output receptacles and built-in network interface. Super-fast switchover between primary and secondary power sources occurs within milliseconds.
$999.18
Provides a redundant A/B power option for non-redundant networking equipment with a single input power cord.
Features ATS (auto-transfer switching).
Switched PDU features enable programmable or real-time power control of individual outlets via built-in network interface.
Digital display continuously reports total output power consumption in amps.
Separate primary & secondary inputs connect to any two compatible power sources.
Integrated Automatic Transfer Switch (ATS) allows PDU to operate from secondary input source when primary input fails
Sequential outlet power-on prevents inrush-related equipment interaction on startup
Programmable or real-time outlet power control via web/network monitoring and control card
Manufacturer Part Number
PDUMH15ATNET
Manufacturer Website Address
http://www.tripplite.com
Marketing Information
Tripp Lite Switched ATS / Auto Transfer Switch provides a redundant power option for single-corded network devices. Dual input cords support separate connection to PRIMARY and SECONDARY power sources. The ATS will normally maintain continuous output to all outlets as derived from the primary input cable. If the primary power source becomes unstable or fails altogether the ATS will switch over to the secondary power source until the primary input is restored and stable. The built-in Java-free HTML5-based LX Platform interface enables full remote access for PDU status monitoring and email notifications via secure web browser SNMP telnet or SSH. It supports 10/100 Mbps auto-sensing for optimum communication with an Ethernet network. Optional EnviroSense2 modules (sold separately) provide a variety of environmental monitoring capabilities. Protocols supported include IPv4 IPv6 HTTP HTTPS SMTP SNMPv1 SNMPv2 SNMPv3 telnet SSH FTP DHCP BOOTP and NTP. Switched PDU features include individually controllable output receptacles. Super-fast switchover between primary and secondary power sources occurs within milliseconds. ATS functionality is supported by any two compatible AC power sources regardless of phase angle to support a variety of advanced redundant power networking applications. Enables fault tolerant hot-swappable UPS protection when used with a single UPS and fully redundant UPS protection when each cord is connected to a separate UPS system. In a two-UPS environment the primary input cable must be supported by a full time sine wave UPS with zero transfer time. Tripp Lite SmartOnline series is highly recommended for use as the primary UPS in a two-UPS application. ATS configurations utilizing separate mains circuits backup generators and even separate utility power grid feeds are fully supported. On-board ATS processor constantly evaluates power quality on both input sources to prevent transfer to the secondary source when unavailable or of lower quality than the primary source. Front input LED's display primary or secondary power availability.
Material(s)
Steel
Mount Type
Rack-mountable
Mounting Orientation
Vertical
Mounting Orientation
Vertical
Mounting Orientation
Vertical
Mounting Orientation
Vertical
Mounting Orientation
Vertical
Mounting Orientation
Vertical
Mounting Orientation
Vertical
Mounting Orientation
Vertical
Mounting Orientation
Vertical
Mounting Orientation
Vertical
Mounting Orientation
Vertical
Mounting Orientation
Vertical
Mounting Orientation
Vertical
Mounting Orientation
Vertical
Mounting Orientation
Vertical
Mounting Orientation
Vertical
Mounting Orientation
Vertical
Mounting Orientation
Vertical
Mounting Orientation
Vertical
Mounting Orientation
Vertical
Mounting Orientation
Vertical
Mounting Orientation
Vertical
Mounting Orientation
Vertical
Number of Cord/Cable
2
Number of Outlets
8
Package Contents
PDUMH15ATNET PDU Switched ATS 120V 15A 8 Outlet
PDU with attached 5-15P input power cord
Detachable C13 to NEMA 5-15P 12 ft/3.6m power cord for optional secondary input
User manuals with warranty information
Package_Includes
Input Power Cord; Detachable 12 ft Power Cord; User Manual with Warranty Information
