Tripp Lite UPS Smart 750VA 600W Rackmount AVR 120V Pure Sign Wave USB DB9 SNMP 1URM

New
Tripp Lite UPS Smart 750VA 600W Rackmount AVR 120V Pure Sign Wave USB DB9 SNMP 1URM - 750VA/600W - 4.9 Minute Full Load - 6 x NEMA 5-15R
$612.35Retail $934.11
  • .75kVA / 750VA / 600W line interactive 1U rackmount UPS, Sine wave output
  • 120V output, Corrects brownouts and overvoltages from 83V to 147V
  • 0.8 Power Factor, Front panel status LEDs
  • Mounting brackets support 2 and 4 post installation
  • 98% line-mode efficiency, 2 switched load banks
  • USB, RS232, EPO and slot for SNMPWEBCARD option
  • 120V NEMA 5-15P input, 6 NEMA 5-15R outlets
By:
Tripp Lite
Manufacturer:
Tripp Lite by Eaton
Item:
SMART750RM1U
UPC Code:
037332118813
Our Part #
TRPSMART750RM1U
Condition
New
$612.35EA
$934.11
Sorry Product is Currently not Available.
Availability Currently out of stock
Great Deals Everyday

You may be also interested

Product description

Tripp Lite UPS Smart 750VA 600W Rackmount AVR 120V Pure Sign Wave USB DB9 SNMP 1URM - 750VA/600W - 4.9 Minute Full Load - 6 x NEMA 5-15R
750VA/600W - 4.9 Minute Full Load - 6 x NEMA 5-15R

Specifications

Additional Information
  • SMART750RM1U line interactive UPS offers battery derived sine wave AC output during power outages voltage regulation during brownouts and overvoltages plus network-grade AC surge suppression
  • 750VA / 450 watt power handling capability with full-time sine wave output offers guaranteed compatibility with networking telecom and other sensitive electronic devices
  • Supports 1U rackmount installation in 2 or 4 post rack enclosures upright tower placement also supported
  • Maintains regulated 120V nominal output during brownouts and overvoltages from 83 to 147V
  • Includes 6 UPS-supported outlets arranged in 2 individually controllable load banks (2 outlets per bank) that can be powered off and back on again via software interface
  • PowerAlert UPS monitoring and unattended shutdown software enables configurable network broadcast messaging pager & email notification event logging and running user-defined script commands
  • Offers simultaneous monitoring by up to 3 directly-connected devices through included USB DB9 and SNMP* interfaces (*requires optional SNMPWEBCARD) or the monitoring of any number of additional UPS systems over IP with included PowerAlert monitoring software. Free PowerAlert enterprise management software is also available for select opportunies
  • Communications ports support messaging of UPS and line power status including on-battery low-battery power restored AC line voltage DC battery voltage and remaining battery capacity
  • Supports timed inverter shutoff after unattended shutdown activate self-test and UPS output power control for scheduled or immediate reboot of connected devices
  • Supports Tripp Lite's WatchDog software application to restore unresponsive programs by systematically restarting applications operating systems and ultimately rebooting completely locked computers by momentarily switching UPS power off and back on again (requires optional WATCHDOGSW)
  • Built-in accessory slot supports SNMP with optional SNMPWEBCARD adapter
  • Emergency Power Off (EPO) interface with cable
  • Multi-function audible alarms and set of 5 front panel LEDs
  • Network-grade AC surge suppression
  • Attractive all-black color scheme
  • UPS battery set ships fully assembled and ready for installation no time consuming connection of internal batteries by user is necessary
  • Two year warranty with $250000 connected equipment insurance (USA & Canada only)
Alarm
Low Battery
Alarm
On Battery
Alarm
Overload
Backup/Run Time (Full Load)
4.90 Minute
Backup/Run Time (Half Load)
13.20 Minute
Battery Chemistry
Sealed Lead Acid (SLA)
Battery Life
6 Year
Certifications & Standards
UL1778 (USA) cUL (Canada) FCC Class A (emissions) NOM (Mexico) Conforms to IEEE 587 / ANSI C62.41 specifications
Cord Length
10 ft
Country of origin
Taiwan
Depth
16.8"
Height
1.8"
Hot Swappable
Yes
Input voltage
120 V AC
Limited Warranty
3 Year
Load Capacity
750 VA/600 W
Load Capacity (VA)
750 VA
Load Capacity (VA)
750 VA
Load Capacity (VA)
750 VA
Load Capacity (VA)
750 VA
Load Capacity (VA)
750 VA
Load Capacity (VA)
750 VA
Load Capacity (VA)
750 VA
Load Capacity (VA)
750 VA
Load Capacity (VA)
750 VA
Load Capacity (VA)
750 VA
Load Capacity (VA)
750 VA
Load Capacity (VA)
750 VA
Load Capacity (VA)
750 VA
Load Capacity (VA)
750 VA
Load Capacity (VA)
750 VA
Load Capacity (VA)
750 VA
Load Capacity (VA)
750 VA
Load Capacity (VA)
750 VA
Load Capacity (VA)
750 VA
Load Capacity (VA)
750 VA
Load Capacity (VA)
750 VA
Load Capacity (VA)
750 VA
Load Capacity (VA)
750 VA
Load Capacity (W)
600 W
Manufacturer Part Number
SMART750RM1U
Manufacturer Website Address
http://www.tripplite.com
Marketing Information

Tripp Lite SMART750RM1U 750VA / .75kVA / 600 watt line interactive sine wave UPS system offers complete power protection for critical network applications in a highly efficient 1U total rack/tower configuration. Simultaneous-use network management interfaces include USB RS-232 and optional SNMP/Web accessory card. Line interactive voltage regulation network-grade surge suppression and long-lasting sine wave AC output during blackouts make this UPS ideal for advanced networking applications in datacenters computer rooms and network closets.

Maximum Operating Temperature
104°F (40°C)
Network Management
SNMP Manageable
Package Contents
  • SMART750RM1U UPS System
  • Mounting hardware
  • Cabling for USB & DB9 monitoring and EPO switching
  • PowerAlert unattended shutdown and UPS/Power monitoring software
  • Warranty information and instruction manual
Plug/Connector Type
NEMA 5-15P
Product Line
SmartPro
Product Name
SmartPro 750RM1U UPS
Rack Height
1U
Receptacle Detail
6 x NEMA 5-15R
Receptacle Detail
6 x NEMA 5-15R
Receptacle Detail
6 x NEMA 5-15R
Receptacle Detail
6 x NEMA 5-15R
Receptacle Detail
6 x NEMA 5-15R
Receptacle Detail
6 x NEMA 5-15R
Receptacle Detail
6 x NEMA 5-15R
Receptacle Detail
6 x NEMA 5-15R
Receptacle Detail
6 x NEMA 5-15R
Receptacle Detail
6 x NEMA 5-15R
Receptacle Detail
6 x NEMA 5-15R
Receptacle Detail
6 x NEMA 5-15R
Receptacle Type
NEMA 5-15R
Status Indicators
5 front panel LEDs - Green POWER LED 3 color BATTERY CHARGE LED 3 color OUTPUT LOAD LEVEL LED red BATTERY WARNING LED.
Total Number of Expansion Slots
1
Typical Battery Recharge Time
4 Hour
UPC Alternates
037332118813 818214637901 818241663614
Waveform Type
Sine Wave
Waveform Type
Sine Wave
Waveform Type
Sine Wave
Waveform Type
Sine Wave
Waveform Type
Sine Wave
Waveform Type
Sine Wave
Waveform Type
Sine Wave
Waveform Type
Sine Wave
Waveform Type
Sine Wave
Waveform Type
Sine Wave
Waveform Type
Sine Wave
Waveform Type
Sine Wave
Waveform Type
Sine Wave
Waveform Type
Sine Wave
Waveform Type
Sine Wave
Waveform Type
Sine Wave
Waveform Type
Sine Wave
Waveform Type
Sine Wave
Waveform Type
Sine Wave
Waveform Type
Sine Wave
Waveform Type
Sine Wave
Waveform Type
Sine Wave
Waveform Type
Sine Wave
Weight (Approximate)
30 lb
Width
17.5"
Brand Name
Tripp Lite
Manufacturer
Tripp Lite by Eaton
Product Type
Line-interactive UPS
