SMART2200VS SmartPro Tower UPS System, 9 Outlets, 2200 VA, 480 J

New
New
New
Featuring compact tower form factors, Tripp Lite's SmartProŽ Tower UPS Systems protect connected equipment including servers, telecom systems and workstations against data loss, downtime and equipment damage due to all power problems. Advanced automatic voltage regulations provides regulated 120V output without using battery power during brownouts and overvoltages. USB or DB9 communication ports enable PowerAlert software to provide UPS and site power monitoring, plus automatic file saves and safe unattended shutdown of connected equipment in the event of a prolonged power failure.
$1,030.21Retail $1,575.00
  • Power protection and battery backup for servers and network hardware.
  • Advanced AVR corrects power sags and overvoltages.
  • USB and serial ports connect to computers for power management.
  • Enables PowerAlert software application.
  • LED indicators signal power, voltage correction, load leval and battery charge state.
  • Manufacturer:
    Tripp Lite
    Item:
    SMART2200VS
    UPC Code:
    037332115874
    Our Part #
    TRPSMART2200VS
    Condition
    New
    $1,030.21EA
    $1,575.00
    Sorry Product is Currently not Available.
    Availability Currently out of stock
    Great Deals Everyday

    You may be also interested

    Product description

    Tripp Lite UPS Smart 2200VA 1600W Tower AVR 120V USB DB9 SNMP for Servers - 2200VA/1600W - 7 Minute Full Load - 7 x NEMA 5-15R, 2 x NEMA 5-20R
    2200VA/1600W - 7 Minute Full Load - 7 x NEMA 5-15R, 2 x NEMA 5-20R

    Specifications

    Additional Information
    • 2200VA / 1600 watt output capacity accommodates a variety of server networking and telecom devices
    • High power density 2.2kVA UPS system occupies only 106 square inches of floorspace with a height of only 14.25 inches
    • Compatible with North American 120V / 60 Hz power as found in the USA Canada and Mexico
    • Offers 7 minutes runtime with a full load of 2200VA and 19 minutes with a half load of 1100VA
    • Line interactive voltage regulation corrects severe brownouts and overvoltages from 79 to 147v back to normal 120v levels without using battery power
    • 9 total outlets (7 NEMA5-15R; 2 NEMA5-15/20R)
    • Includes NEMA 5-20 straight blade 20 amp input plug connection; package includes optional user installable NEMA 5-15 input plug connection
    • Notification of system status via 5 LEDs and multi-function audible alarms
    • Included PowerAlert Software provides e-mail or pager notification of power problems and the simultaneous automatic unattended shutdown of multiple servers
    • 4 built-in communications ports (2-DB9 2-USB) for remote monitoring and unattended shutdown
    • Slot for SNMP/web card (part#: SNMPWEBCARD) and environmental sensor (part#: ENVIROSENSE) for remote communications in large IP environments
    • Supports Tripp Lite's WatchDog software application to restore unresponsive programs by automatically restarting them and rebooting completely locked computers by automatically switching UPS power off and back on again
    • Communication ports support on battery low battery power restored AC line voltage DC battery voltage load percentage battery charge current battery capacity internal UPS temperature and line frequency status messaging. Interface supports timed inverter shutoff after unattended shutdown activate self-test and 10 second reboot of connected equipment
    • 3 pairs of customized load management receptacles can be individually powered off and back on again via software interface to reboot remote equipment or automatic "load shedding" of less critical loads to extend battery runtime for the most critical equipment
    • Built-in Emergency Power Off (EPO) interface supports emergency shutoff in large facilities
    • Hot-swappable / user replaceable batteries allow on-site battery replacement through the front panel without powering off connected equipment or removing the UPS from the rack
    • UPS battery set ships fully assembled and ready for use no time consuming connection of individual internal batteries by user is necessary
    • UL (USA) cUL (Canada) NOM (Mexico) FCC Class A
    • $250000 Ultimate Lifetime Insurance. No warranty cards required for coverage!
    • 2 year manufacturers product warranty
    Alarm
    Overload
    Alarm
    On Battery
    Alarm
    Low Battery
    Alarm(s)
    Audible
    Automatic Voltage Regulation (AVR)
    Yes
    Backup Time at Full Load
    7 minutes @ 2200 Volts
    Backup Time at Half Load
    19 minutes @ 800 Watts
    Backup/Run Time (Full Load)
    7 Minute
    Backup/Run Time (Half Load)
    19 Minute
    Battery Chemistry
    Sealed Lead Acid (SLA)
    Battery Life
    6 Year
    Battery recharge time
    4 h
    Certifications & Standards
    UL1778 (USA) cUL (Canada) FCC Class A (emissions) NOM (Mexico) Conforms to IEEE 587 / ANSI C62.41 specifications
    Color(s)
    Gray
    Compliance Standards
    FCC Class A Certified
    Compliance Standards
    Conforms to UL1778 Standards
    Compliance Standards
    RoHS Compliant
    Compliance Standards
    CSA Certified
    Connected Equipment Guarantee/Warranty
    $250000 Connected Equipment Guarantee
    Connector/Port/Interface
    DB9
    Connector/Port/Interface
    USB
    Cord Length
    8 ft
    Country of origin
    Switzerland
    Depth
    12"
    Disclaimer Statement
    Run Time based on a load equivalent to one half of the unit's capacity.
    Emergency Power Off (EPO)
    Yes
    Form factor
    Tower
    Height
    14.3"
    Height
    14 1/4"
    Hot Swappable
    Yes
    Input frequency
    60 Hz
    Input voltage
    120 V AC
    Joules Of Surge Protection
    480 J
    Limited Warranty
    3 Year
    Load Capacity
    2200 VA/1600 W
    Load Capacity (VA)
    2200 VA
    Load Capacity (VA)
    2200 VA
    Load Capacity (VA)
    2200 VA
    Load Capacity (VA)
    2200 VA
    Load Capacity (VA)
    2200 VA
    Load Capacity (VA)
    2200 VA
    Load Capacity (VA)
    2200 VA
    Load Capacity (VA)
    2200 VA
    Load Capacity (VA)
    2200 VA
    Load Capacity (VA)
    2200 VA
    Load Capacity (VA)
    2200 VA
    Load Capacity (VA)
    2200 VA
    Load Capacity (VA)
    2200 VA
    Load Capacity (VA)
    2200 VA
    Load Capacity (VA)
    2200 VA
    Load Capacity (VA)
    2200 VA
    Load Capacity (VA)
    2200 VA
    Load Capacity (VA)
    2200 VA
    Load Capacity (VA)
    2200 VA
    Load Capacity (VA)
    2200 VA
    Load Capacity (VA)
    2200 VA
    Load Capacity (VA)
    2200 VA
    Load Capacity (VA)
    2200 VA
    Load Capacity (W)
    1600 W
    Manufacturer Part Number
    SMART2200VS
    Manufacturer Website Address
    http://www.tripplite.com
    Marketing Information

    Tripp Lite's SMART 2200VS intelligent line interactive UPS protects server networking and telecommunications equipment from blackouts voltage fluctuations and transient surges. Small footprint tower UPS system occupies only 106 square inches of floor space with a height of only 14.25 inches. Large capacity 2200 VA/ 1600 watt rated UPS system offers 7 minutes runtime at full load and 19 minutes at half load during power failures. Line interactive voltage regulation corrects brownouts as low as 79V and overvoltages as high as 147V to fully regulated 120V nominal output for smooth continuous operation of connected equipment. Includes a total of 9 outlets 3 pairs of which can be individually powered off and back on via software interface to selectively reboot remote equipment or shed less critical loads to extend battery runtime for more critical loads. Includes 2 DB9 and 2 USB enhanced monitoring ports for unattended shutdown remote control and monitoring of UPS system and power data. Ships in attractive gray color scheme. Compatible with Tripp Lite's PowerAlert and Watchdog service software.

    Maximum Operating Temperature
    104°F (40°C)
    Model Name/Number
    SmartProŽ SMART2200VS
    Network Management
    SNMP Manageable
    Number of Outlets
    9
    Number of Outlets/Type
    9 UPS/Surge
    Package Contents
    • SmartPro SMART2200VS UPS
    • SMART 2200VS UPS System PowerAlert Software and cabling Warranty information Instruction manual
    Plug/Connector Type
    NEMA 5-20P
    Post-Consumer Recycled Content Percent
    0%
    Pre-Consumer Recycled Content Percent
    0%
    Product Line
    SmartPro
    Product Name
    SmartPro SMART2200VS UPS
    Product_Description
    POWERUPS 2200VABK
    Protection Type
    Power
    React Time
    Instantaneous
    Receptacle Detail
    2 x NEMA 5-20R
    Receptacle Detail
    7 x NEMA 5-15R
    Receptacle Detail
    2 x NEMA 5-20R
    Receptacle Detail
    7 x NEMA 5-15R
    Receptacle Detail
    2 x NEMA 5-20R
    Receptacle Detail
    7 x NEMA 5-15R
    Receptacle Detail
    2 x NEMA 5-20R
    Receptacle Detail
    7 x NEMA 5-15R
    Receptacle Detail
    2 x NEMA 5-20R
    Receptacle Detail
    7 x NEMA 5-15R
    Receptacle Detail
    2 x NEMA 5-20R
    Receptacle Detail
    7 x NEMA 5-15R
    Receptacle Detail
    2 x NEMA 5-20R
    Receptacle Detail
    7 x NEMA 5-15R
    Receptacle Detail
    2 x NEMA 5-20R
    Receptacle Detail
    7 x NEMA 5-15R
    Receptacle Detail
    2 x NEMA 5-20R
    Receptacle Detail
    7 x NEMA 5-15R
    Receptacle Detail
    2 x NEMA 5-20R
    Receptacle Detail
    7 x NEMA 5-15R
    Receptacle Detail
    7 x NEMA 5-15R
    Receptacle Detail
    2 x NEMA 5-20R
