Tripp Lite 16-Port Cat5 IP KVM Switch 1 Local 2 Remote User 1URM Rackmount
Tripp Lite 16-Port Cat5 IP KVM Switch 1 Local 2 Remote User 1URM Rackmount - 16 Computer(s) - 1 Local User(s) - 2 Remote User(s) - 1920 x 1080 - 20 x Network (RJ-45) - 2 x USB1 x VGA - Rack-mountable - 1U - TAA Compliant
$1,441.00EA
$2,329.60
$2,329.60
By:
Tripp Lite
Manufacturer:
Tripp Lite by Eaton
Item:
B072-016-IP2
UPC Code:
037332177278
Our Part #
TRPB072016IP2
Condition
New
- Simultaneous support for 3 users (1 local, 2 remote)
- Java-based application allows for control of a target server via web browser from any location over a secure IP connection.
- Non-Browser client available via the Support section, which can by-pass browser related Java Security prompts upon login
- Free Management Software available to Access and Control all of your Tripp Lite NetCommander IP KVM's (B070 and B072 IP series) from a single interface
- Remote authentication support - RADIUS and LDAP/S
- Supports both IPv4 and IPv6
- PDU Control - Add IP PDU's as devices that can be controlled by the KVM. Assign individual ports on the KVM to a PDU port to Power Cycle or Power Off/On the computer/server connected to that port.
- Dual Serial Ports - Connect serial manageable devices such as PDU's, firewalls, and routers.
- Dual Ethernet and Power provides redundancy in the event of a crash.
- Fast Virtual Media
You may be also interested
Product description
Tripp Lite 16-Port Cat5 IP KVM Switch 1 Local 2 Remote User 1URM Rackmount - 16 Computer(s) - 1 Local User(s) - 2 Remote User(s) - 1920 x 1080 - 20 x Network (RJ-45) - 2 x USB1 x VGA - Rack-mountable - 1U - TAA Compliant
16 Computer(s) - 1 Local User(s) - 2 Remote User(s) - 1920 x 1080 - 20 x Network (RJ-45) - 2 x USB1 x VGA - Rack-mountable - 1U - TAA Compliant
Specifications
Certifications & Standards
- UL 60950-1 (USA)
- CSA (Canada)
- FCC Part 15 Class A
- CE IEC 60950-1
Country of origin
Taiwan
Depth
11"
Environmental Certification
RoHS
Environmentally Friendly
Yes
Form factor
Rack-mountable
Graphic Mode
Full HD
Height
1.7"
KVM Technology
Digital
KVM Technology
Digital
KVM Technology
Digital
KVM Technology
Digital
KVM Technology
Digital
KVM Technology
Digital
KVM Technology
Digital
KVM Technology
Digital
KVM Technology
Digital
KVM Technology
Digital
KVM Technology
Digital
KVM Technology
Digital
KVM Technology
Digital
KVM Technology
Digital
KVM Technology
Digital
KVM Technology
Digital
KVM Technology
Digital
KVM Technology
Digital
KVM Technology
Digital
KVM Technology
Digital
KVM Technology
Digital
KVM Technology
Digital
KVM Technology
Digital
KVM Technology
Digital
KVM Technology
Digital
Limited Warranty
3 Year
Manufacturer Part Number
B072-016-IP2
Manufacturer Website Address
http://www.tripplite.com
Marketing Information
Tripp Lite's B072-016-IP2 KVM Switch is the optimal solution for controlling up to 16 computers/servers locally from across the room down the street or around the globe on a network or the Internet.This KVM switch can be accessed and controlled remotely so there's no need to travel to the server room or network closet. A Java-based application allows access via web browser from any secure IP connection; a non-browser client that can bypass browser-related Java Security prompts is available. The B072-016-IP2 uses inexpensive user-supplied Cat5e/6/6a cabling with Server Interface Units (sold separately) so you can connect computers/servers located up to 100 ft. away from the switch. This switch features dual Ethernet ports and dual power supplies; if one fails the other takes over keeping access uninterrupted. Switch easily between the 16 ports using an on-screen display (OSD) hotkey commands or a remote toolbar. Multi-level password protection prohibits unauthorized users from accessing connected computers and a local user and up to two remote users can each log on and access different ports simultaneously. Two serial ports allow control of serial-manageable devices such as IP PDUs firewalls and routers; individual ports can be assigned to an IP PDU port to power on/off the server connected to that port. This KVM switch is compatible with Windows and Linux operating systems and it supports VGA video resolutions up to 1920 x 1080 @ 60 Hz. Heavy-duty steel housing stands up to frequent use. Virtual Media allows an .iso file to be mounted to a target server and accessed as if it were stored directly on it. Virtual Media data transfer rates up to 12Mbps are supported when using a B078-101-USB2 Server Interface Unit. Other features include RADIUS and LDAP/S authentication system-sent SNMP messaging and an event log that tracks logins reboots and network setting changes. Free NetCommander-AXS Management Software is available to access and control all of your Tripp Lite NetCommander IP KVM switches (B070 and B072 series). From a single interface you can access server ports on any of your KVM switches power cycle or power on/off outlets of IP PDUs and manage KVM settings. This software can be downloaded free of charge from the model support page for the B072-016-IP2.
Maximum Operating Distance
100 ft
Maximum video resolution
1920 x 1080
Number of Computers Supported
16
Number of Network (RJ-45) Ports
20
Number of USB Ports
2
Number of VGA Ports
1
Package Contents
- 16-Port 2+1 User NetCommander Cat5 IP KVM Switch
- Rackmount Hardware
- 2 x Power Cords
Platform Supported
Linux
Platform Supported
PC
Product color
Black
Product Line
NetCommander
Product Name
16-Port 2+1 User NetCommander Cat5 IP KVM Switch
Rack Height
1U
UPC Alternates
037332177278 373321772780 801096944939
Weight (Approximate)
7.46 lb
Width
17.3"
Brand Name
Tripp Lite
Manufacturer
Tripp Lite by Eaton
Product Type
KVM Switchbox
